Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base

Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base
Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base

Large Image :  Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base Get Best Price

Product Details:
Place of Origin: China
Brand Name: GF truss
Certification: CE, SGS, TUV, ISO
Model Number: GF-LGS
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$10-US$5000/set
Packaging Details: Flight Case or air bubble film
Delivery Time: 5-7days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000set/week
Contact Now
Detailed Product Description
Material: Aluminum Alloy 6061-T6 Color: Black Or Silver
Size: 0.5M, 0.8M, 1M, OEM Base Material: Steel
Ground Beam: Aluminum Alloy Usage: Outdoor/Indoor LED Screen Haning
Cabinet Size: For All Cabinets Lead Time: 5-7days
High Light:

Aluminum Ladder Led Screen Truss

,

0.8M Led Screen Truss

,

Adjustable Base Led Screen Truss

Custom Led Screen Truss Aluminum Ladder Truss , Outdoor Led Display Screen

Product Features:



1) Easy to install and assemble.

2) Lightweight, Easy portability

3) strong loading capacity.

4) Durable Structure - excellent geometry between main tubes and diagonal brace tubes.

5) Decorative appearance

6) A full range of corners, bases and accessories are available

7) CE certificated.


2. Products Details

 Part of LED Screen   Support   Specification
  Background   Supporter

  Material: aluminum alloy 6061-T6
  Main Tube: 50*3mm
  Measure: 50*500*1000mm
  According to cabinet Size, also can do 0.5M, 0.8M and so on.
  Adjustable Base   Material: aluminum alloy 6061-T6
  Main Tube: 50*3mm
  Measure: 150*500*1000mm
  Ground Beam

  Material: aluminum alloy
  Size:69×138×6mm
  Length:1M/pc
  With Easy Lock
  Measure: 1000X200X69mm
  According to cabinet Size, also can do 0.5M, 0.52M, 0.64M, 0.96M and so on
  Lock+ Clamp   Material: aluminum alloy+Iron
  stretchable clamp
  Footboard

  Material: aluminum alloy + 9mm plywood
  Measure: 380*85*1000mm
  According to cabinet Size, also can do different size footboard.
  Horizontal Pipe

  Material: aluminum alloy
  Length:1M/pc
  Measure: 50*50*1000mm

  According to cabinet Size, also can do different size footboard.


3. Products Detail Pictures:


Ground Beam

Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 0



Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 1



Screw Lock for Cabinet corners

Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 2



Fast Lock

Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 3



Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 4



Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 5



Adjustable Height 0.7-1M from ground

Indoor Aluminum Alloy 6061 T6 LED Screen Truss System Ground Support for LED Display Cabinet 6



Aluminum Ladder Led Screen Truss Outdoor With Adjustable Base 7



Advantages



1. Applicable occasions: Various of performance activities, News conference, The large and medium-sized party, Interior multi-function hall, Hotel, Wedding and so on.

2. Professional structure: Simple Structure and Suitable for fixed installation as well as Saving storage and transportation costs.

High-grade appearance: The abroad flow structure and appearance and applicable material fastidious, Durable.
